XTR 110 S3 PIT BIKE 72HR SALE
Affordable FUN Ideally sized for teens or small adults, the XTR 110 Manual Kick and E-Start PIT BIKE is perfect for beginners or as a fun play big for experienced riders. Powered by a 110cc single-cylinder 4-stroke engine and 4-speed transmission, and riding on 14 inch front wheel and 12 rear ideal as a pit bike or trail riding. A manageable 28 inch seat height and light 137 pounds makes it accessible for most youth. Hydraulic disc brakes on the front and rear of the bike provide excellent stopping power and enhance handling in hilly terrain, in turns and during technical trail riding. Reliable electric-start and kick start. Several colors.
NOT FOR SALE IN STATE OF CALIFORNIA - NOT CARB APPROVED
Average delivery time for most of the nation: 7-10 business days after ordering. Have questions before you decide? Call us at 714.888.5114 or text 714.888.5114 ... licensed dealer offering local pickup or shipping nation wide.
Need this unit shipped to Alaska, Hawaii, or Puerto Rico? Contact us.
SPECIFICATIONS
|
XTR-110CC PIT BIKE |
|
|
CONFIGURE |
|
| Colors available | BLACK, RED, GREEN |
| Decals(Y/N) | YES |
| Assembly required | FRONT WHEEL,HANDLEBAR,REAR SHOCK |
| ENGINE INFO | |
| Engine Type | 110CC, Single-cylinder, 4 stroke manual, air-cooled |
| Engine brand | Zongshen 152FMH Horizontal |
| Displacement | 107 ml |
| Cooling | AIR COOLED |
| Max Power | 6.7 HP @ 8000 RPM |
| Max torque | 4.94 ft-lb @ 5500 RPM |
| Compression | 9.1:1 |
| Max speed | 41 mph (with adjustable speed limiter) |
| Ignition | CDI |
| Starting system | KICK AND ELECTRIC START (12v battery) |
| Battery | 12V4ah MAINTENANCE FREE LEAD ACID |
| Carburetor brand | PZ22 Jingke |
| Engine oil | 10W40 synthetic JASO MA/MA2 (motorcycle wet clutch) |
| Spark Plug | A7TC |
| CHASSIS ETC. | |
| Clutch | MANUAL |
| Transmission | 4 GEAR MANUAL (N-1-2-3-4-5) |
| Driveline | #428 Chain (14T, 41T Sprockets) |
| Brakes,front/rear | FRONT/REAR DISC |
| Brake operation | FRONT HAND REAR FOOT |
| Tires,front/rear | F:60/100-14 R:80/100-12 off-road knobby tires |
| Rims | F:1.6x14, R:1.85x12 Cast |
| Front Fork | Non-Adjustable Inverted 650mm, Travel 140mm, Tube 33mm |
| Rear Shock | Coil Spring 270mm, Travel 43mm |
| Swing Arm | 320mm Steel |
| Fuel capacity/type | 0.92 gal / Premium gasoline octane level 91 or greater |
| Box Weight G.W. | 163 lbs |
| Dirt Bike Dry Weight | 137 lbs |
| Max load | 170 lbs |
| DIMENSIONS | |
| Wheelbase | 41.33 inches |
| Dirt Bike Dimensions | L60 x W29 x H38 inches |
| Height to seat | 32 inches |
| Min ground clearance | 9 inches |
| Carton Dimensions | L53 x W15 x H26 inches |
*NOT FOR SALE in CALIFORNIA - MSRP for GEORGIA IN STORE PURCHASES does not include destination charges, taxes, licenses fee or Dealer PDI warranty preparation.
