TM EAGLE MINI XRS+ AUTOMATIC GO KART
TRAILMASTER Mini XRS Plus kids gokart is a slightly larger version of their hugely popular Mini XRS model. The Plus features a powerful and reliable 4 stroke 5.5 horsepower OHV engine and automatic transmission. A chain driven rear live axle puts maximum power to the ground for excellent traction, and the full front and rear coil-over oil-damped shock suspension and rack-and-pinion steering makes the Mini XRS kart easy to handle for small kids. An adjustable seat makes it easy to fit even the smallest riders. Safety features include a rear disc brake, seat belts, padded overhead brush guard and a speed limiter. Your choice of color.
PRODUCT INFORMATION
|
Engine Information
|
|
|
Engine type:
|
4-stroke, single cylinder, air cooled
|
|
Displacement:
|
163cc
|
|
Max HP:
|
5.5hp/3600rpm
|
|
Max torque:
|
8 lb ft/3600rpm
|
|
Bore x stroke:
|
2.6 x 1.8 inches
|
|
Max speed:
|
12.4mph
|
|
Climbing ability:
|
12 degrees
|
|
Ignition:
|
C.D.I
|
|
Starting system:
|
Manual Pull Start
|
|
Battery:
|
No
|
|
Carburetor brand:
|
JF (RX)
|
|
Engine oil:
|
SAE 15W-40
|
|
General Information
|
|
|
Clutch:
|
Automatic
|
|
Driveline / Driving wheel:
|
Chain / Dual wheel drive
|
|
Suspension, F / R:
|
Dual A-arm / Double Oil Damped Shock
|
|
Brakes, F / R:
|
No / Disc
|
|
Tires, F / R:
|
4.10-6 / 13 x 5-6
|
|
Fuel capacity:
|
1.2 gal
|
|
Weight, G.W. / N.W.:
|
209 / 176 lbs
|
|
Max load:
|
400 lbs
|
|
Dimension Information
|
|
|
Wheelbase:
|
41.7 inches
|
|
OA L x W x H:
|
58.5x36x43 inches
|
|
Height to seat:
|
7.5 inches
|
|
Min ground clearance:
|
3.5 inches
|
|
Pedal to seat back: standard: 29'', can be adjusted to 26'' or 23''
|
|
