GEN IV MADDOG PMZ50-21 50cc SCOOTER
ICEBEAR PMZ50-21 GEN IV MADDOG 50cc SCOOTER 49.5cc, Generation IV Maddog, FR Disc/RR DrumBrake, Aluminum FR 12"/RR 12", LED lights, Digital Speedometer
Product Details
| Engine | 50cc, 139QMB, XinBa |
| Transmission | Automatic 35-40 MPH |
| Drive type | Belt |
| Belt and or chain size | Belt:788*18*28 |
| Starter System | Elec/kick start |
| Fuel system | Gasoline, 1.2gal, carbureted |
| Brake (Front/Rear) | Disc/Drum |
| Tire size(Front/Rear) | 120/70-12 ; 140/70-12 |
| Wheel size and type(Front/Rear) | 12, Alunimum |
| Oil capacity and type (in liters) | 0.8L, 10w40 aircooled engine oil (non-synthetic) |
| Gear oil type and capacity( in liters) | GL-3, 0.25L |
| Battery | 12V/7A |
| Light | Led lights |
| Suspension(Front/Rear) | Dual Telescopic Forks / Single shock |
| Dimensions(in inch) | Assembled(LxWxH): 79.5x26.4x36.6, Crated(LxWxH): 74.8x22.4x32, Seat height: 21.6, Wheelbase: 61.4 |
| Weight(net/gross/capacity) | 191.8/257.9 lbs |
| weight capacity | 242 lbs |
| Ground Clearance (in inch) | 4.3 |
| Assembly Require | Front wheel, front and rear fenders, handlebars, mirrors speedometer,battery |
| Any special features | Include: digital speedometer, horn, odometer, bar end mirrors |
| EPA/carb approved | EPA Approve, CARB Exempt |
