TRAILHAWK YOUTH 10 120cc Automatic with Reverse

$2,173.49

AFFORDABLE FUN RIVAL The TrailHawk 10 is designed specifically for young riders to start learning the ropes of ATV riding. It’s loaded with great features to let your young rider explore and enjoy the outdoors. Supervising adults will love the Trailhawk 10’s safety features like Wireless Engine Shut Off, Throttle...

Size guide

Delivery

All orders shipped with UPS Express.

Always free shipping for orders over US $250.

All orders are shipped with a UPS tracking number.

Returns

Items returned within 14 days of their original shipment date in same as new condition will be eligible for a full refund or store credit.

Refunds will be charged back to the original form of payment used for purchase.

Customer is responsible for shipping charges when making returns and shipping/handling fees of original purchase is non-refundable.

All sale items are final purchases.

Help

Give us a shout if you have any other questions and/or concerns.

Email: help@example.com

Phone: +1 (23) 456 789

Color

SKU:
Categories: ATVs, UTVs

Wireless Engine Shut Off

The TrailHawk 10 comes with a unique Wireless Engine Shut Off key fob, giving the supervising adult an extra level of control. A simple push of the shut off button will turn the engine off and the TrailHawk 10 coasts to a stop. When the child has corrected him- or herself, the adult can push the remote start to restart the engine for them.

Electronic Gauge w/ Gear Indicator

Name: WHITE-RED TRAILHAWK YOUTH 10 120cc Automatic with Reverse
SKU: RIVAL-TRAILHAWK-10-WHTRED
Price: 2173.49 USD

The TrailHawk 10 features an LCD gauge display. Your rider can see vehicle speed, engine RPM, hour meter and gear selection. The ATV has an easy-to-shift transmission for forward, neutral and reverse. It uses a no-hassle, no-belt, fully automatic drive for simplicity. The shift lever is conveniently located on the left side of the unit.

Prototype unit shown. Final production TrailHawk 10 may change.

Specifications

Colors	black/green, white/green, black/orange, white/orange, black/red, white/red
Body length (L) mm	1500mm	Vehicle width mm	980mm
Vehicle height (B) mm	965mm	Seat height (H) mm	670mm
Wheelbase of front and rear wheels (L1) mm	970mm	Handle tube work center width (B2)	620mm
Deadweight (㎏)	60kg	Loaded bottom-to-ground distance	100mm
Turning radius	2.6m	Steering angle (α)	32 ° ± 1 °
Engine model	154FMI	Engine capacity	120CC
Bore x Stroke (mm)	52.4 * 55.5	Cylinder working volume (mm)	119.6
Compression ratio	9.5: 1	Engine torque	8.0Nm / 6500r / min
Engine calibration power	5.5kw / 7500r / min	Minimum no-load stable speed	1500 ± 100r / mi
Minimum fuel consumption rate	≤ 367g / kw / h	Ignition method	CDI
Start way	Electric start	Engine transmission mode	Chain drive
Clutch way	Automatic clutch	Shifting mode	foot
Carburetor model	PZ22	Fuel tank capacity (L)	2.2L
Front wheel rim model	8 inch	Rear wheel rim model	8 inch
Front wheel tire model	19 * 7-8	Rear tire model	18 * 9.5-8
Front brake method	Hand brake hub brake	Rear brake method	Handbrake disc brake
Front braking force	≥ 466N	Rear braking force	≥ 485N
Front shock	Spring shock 315mm	Rear shock absorption	Spring shock absorption 310mm
Climbing angle	＞16 °	Maximum speed (Km / h)	≧ 50KM / H
Starting performance	≤ 15S	Economy speed fuel consumption (L / 100km)
Remote control (yes / no)	Yes	Maximum noise	≦ 80dB
Speed limit (with / without)	YES	Flameout switch (yes / no)	YES
Battery specifications	12V5AH	Spark plug model / electrode gap mm	0.6-0.7mm
Vehicle Net Weight (㎏)	110.4KG	Gross weight	129.2
Vehicle maintenance quality (including oil)	112 (filled with 1.6kg )	Packaging carton (package 2.8 kg)	1370 × 770 × 610
Packaging iron frame (16 kg)	1360 × 760 × 620	40 ‘ high container packing	100 units
