TM BOBCAT MID XRS

TRAILMASTER

  • $1,299.00

"SHOP NOW, PAY LATER" FINANCE up to $2500 at checkout, 4 intrest-free-payments with sezzle.

TRAILMASTER Mid-XRS Go Kart takes on the toughest trails with a reliable gas overhead valve engine and it's fully automatic CVT clutch delivers more torque to the wheels for better traction and climbing power. Dual coil over, double oil dampened shocks on the rear swing arm suspension enhance traction on slippery, loose terrain and help make the hydraulic rear disc brake more efficient for quicker stopping. Everything on the XRS is built to be reliable and easy to maintain. Trouble-free manual pull start means there are no electronics to break and no battery to replace. The tubular steel frame features a full upper brush guard cage, side rails and an enclosed belly pan for all around protection. The double bench seat with 3-point safety belt offers plenty of room for taking a friend along for the ride! Available in several colors.

Specifications

  • Engine Type: 196cc, 4-Stroke, Air Cooled, Single Cylinder
  • Max horsepower: 6.3hp/3600rpm
  • Max torque: 9.6lb ft/3600rpm
  • Fuel Requirement: unleaded
  • Start Type: Manual pull start
  • Transmission: Fully Automatic CVT, Chain/Dual Wheel Drive
  • Ignition: CDI
  • Brakes (Front/Rear): None / Hydraulic Disc
  • Suspension (Front/Rear): Dual A-Arm with shocks / Swing arm Rear with Double Oil Damped Shocks
  • Tires (Front/Rear): 145x70-6 / 16x6-8
  • Max speed: 31 mph approximate
  • Climbing: 12 degrees
  • Seat belts: 3-point Harnesses
  • Speed Limiter
  • Fuel Capacity: 1 gal.
  • Wheelbase: 48.4 inches
  • Gross weight: 386 lbs.
  • Net weight: 330 lbs.
  • Max load: 400 lbs.
  • Dimensions (inches): 67L x 43.3W x 51.2H
  • Ground Clearance: 2.8 inches
  • Height to seat: 10.2 inches
  • Pedal to seat back: Adjustable from 30 to 34.5 inches
